Okuma MX-40HA Horizontal CNC Milling Machine with Pallet Changer... this unit needs a Cam Box for the tool changer

This is a Okuma MX-40HA Horizontal CNC Milling Machine with Pallet Changer... this unit needs a Cam Box for the tool changer.

NOTE: This machine runs perfectly but needs a Cam Box for the tool changer. We have the parts number if needed.

The ATC CAM box and tool arm are still assembled in the machine.

There is a thrust bearing in the CAM box that broke and needs to be replaced.

Other than tool changing, the machine works perfectly.

Okuma Horizontal Machining Center

Model MX-40HA

OPS 7000 M Controller

Serial Number 0246

X Axis Travel: 22.04″

Y Axis Travel: 24.01″

Z Axis Travel: 22.04″

Pallet Size: 15.75 x 15.75″

Max Pallet Load: 881.8 LBS

Spindle Speed: 7,000 RPM

Spindle Motor: 26.85 HP

Tool Changer: 60 ATC

Equipped with:

Chip Conveyor

Coolant Thru Spindle

360,000 Full 4th

Dimensions: 157″ x 107.48″ x 98.03″

Weight: 22,047 LBS

NOTE: Tombstones Tooling Fixtures Shown, are NOT Included

WE CAN FINANCE!!! PLEASE INQUIRE!!

There will be a rigging charge of $1700 to load this machine.

WSPT# LQC-00001-040824-C

R070524

Picture 032824

* All information deemed accurate but may vary from model to model.

Contact Larry for any questions you may have... GOOGLE "Larry Razza Machinery"

Contact us at Four Zero One - Nine Six Five - Five Five Five Seven
